Description
Bently 330130‑040‑13‑05
Technical Specifications: Cable Length: 4.0 m Nominal Impedance: 75 Ω Cable Construction: FluidLoc triaxial coaxial structure, armored Operating Temperature Range: ‑51 °C ~ +177 °C Minimum Static Bend Radius: 25.4 mm Connector Type: Click‑Loc gold‑plated FluidLoc explosion‑proof self‑locking coaxial connector with external connector protector Agency Certifications: ATEX, IECEx, CSA intrinsically‑safe approvals Maximum Tensile Load: 330 N Capacitance: 69.9 pF/m Net Weight: 610 g Compatible System: 3300 XL 8 mm proximity transducer system
Functional Features: Interlocked‑stainless‑steel‑armor‑resists‑cutting‑‑squeezing‑‑and‑mechanical‑impact‑damage.‑FluidLoc‑reinforced‑sealing‑assembly‑prevents‑oil‑mist‑‑and‑liquid‑medium‑invading‑connector‑internal‑contact‑cavity.‑Hard‑connector‑protector‑shell‑provides‑extra‑anti‑collision‑‑anti‑scratch‑protection‑for‑connector‑parts.‑Explosion‑proof‑certified‑Click‑Loc‑self‑locking‑connector‑eliminates‑vibration‑caused‑loosening‑‑tool‑free‑assembly‑and‑removal.‑Full‑triaxial‑shielding‑structure‑suppresses‑industrial‑EMI‑RFI‑electromagnetic‑interference.‑Dual‑end‑CableLoc‑strain‑relief‑molding‑sections‑absorb‑tensile‑stress‑‑avoid‑inner‑conductor‑fracture.‑Factory‑pre‑matched‑electrical‑performance‑removes‑on‑site‑recalibration‑work.‑FEP‑insulation‑material‑maintains‑stable‑signal‑transmission‑performance‑under‑heavy‑oil‑mist‑‑dust‑‑and‑pollution‑conditions‑within‑hazardous‑classified‑locations.‑Meets‑intrinsically‑safe‑installation‑specifications‑for‑explosive‑gas‑zones.
Application Scenarios: Shaft‑vibration‑‑axial‑thrust‑displacement‑‑and‑Keyphasor‑phase‑reference‑signal‑transmission‑for‑large‑steam‑turbines‑‑centrifugal‑compressors‑‑gear‑boxes‑‑and‑generators‑in‑petrochemical‑‑refinery‑‑and‑coal‑chemical‑hazardous‑classified‑areas.‑Applied‑for‑field‑wiring‑routes‑which‑simultaneously‑require‑mechanical‑damage‑protection‑‑heavy‑oil‑mist‑resistance‑‑connector‑anti‑collision‑‑and‑explosion‑protection‑qualification.
Performance Parameters: Center Conductor DC Resistance: 0.88 Ω ±0.10 Ω Shield Conductor DC Resistance: 0.26 Ω ±0.06 Ω Connector Mating Cycle Life: More than 1000 insert‑extract cycles Maximum Operating Relative Humidity: 93 % non‑condensing
Material Composition: Inner Insulation Layer: Fluoroethylene‑Propylene (FEP) Signal Conductor: High‑purity silver‑plated copper Outer Armor Layer: AISI 302 interlocked stainless‑steel Connector Body: Gold‑plated brass alloy with explosion‑proof structural qualification FluidLoc Sealing Component: Reinforced fluororubber composite material for hazardous‑area service Connector Protector Shell: High‑strength glass‑filled PPS engineering plastic
Structural Features: 75‑Ω‑FluidLoc‑structure‑triaxial‑inner‑cable‑wrapped‑by‑interlocked‑corrugated‑stainless‑steel‑armor‑jacket.‑Both‑cable‑ends‑adopt‑ATEX‑IECEx‑CSA‑qualified‑Click‑Loc‑FluidLoc‑explosion‑proof‑self‑locking‑connectors‑‑each‑connector‑equipped‑with‑detachable‑hard‑plastic‑protector‑shell.‑CableLoc‑strain‑relief‑transition‑sections‑molded‑at‑two‑cable‑terminals.‑Whole‑cable‑assembly‑adopts‑integral‑manufacturing‑process‑‑without‑intermediate‑splice‑joints.
