Description
Bently 330130-045-02-00
Technical Specifications
- Product Series: 3300 XL 8mm Extension Cable
- Cable Length: 4.5 meters (14.8 feet)
- Impedance: 75Ω Triaxial Cable
- Connector Type: ClickLoc
Functional Features
- Enhanced Routing Flexibility: The 4.5-meter length accommodates complex machinery layouts where standard 4.0-meter cables fall short.
- Superior Shielding: Triaxial construction provides robust protection against industrial electrical noise and VFD interference.
- Secure Connection: ClickLoc connectors feature a positive locking mechanism to withstand high-vibration environments.
Application Scenarios
Ideal for large industrial fans, gearboxes, and centrifugal pumps where the monitoring junction box is located at a moderate distance from the measurement point.
Performance Parameters
- Operating Temperature: -52°C to +177°C (-62°F to +350°F)
- Minimum Bend Radius: 25.4 mm (1 inch)
- Tensile Strength: High, utilizing CableLoc patent design to withstand significant pulling forces.
Material Composition
Precision copper core, FEP insulation, braided copper shielding, and a ruggedized outer jacket.
Structural Characteristics
Continuous triaxial cable assembly with integrated ClickLoc connectors designed for secure, tool-less mating with the probe and transducer.
Working Principle
Transmits the high-frequency impedance variation signal from the proximity probe to the signal conditioning electronics (Proximitor) with exact capacitance matching.
Installation Requirements
Maintain the minimum bend radius of 25.4 mm during routing. Avoid routing parallel to high-current AC conductors. Use strain relief if the cable is suspended vertically.
Usage Precautions
Never use an extension cable to bridge a gap if the total system length exceeds the Proximitor’s rated capacity. Protect the cable from chemical spills and sharp edges.
