Description
Bently 330930-060-00-05
Technical Specifications
- Cable Type: 3300 XL Extension Cable
- Length: 6.0 meters (19.7 feet)
- Construction: Standard
- Agency Approval: 05 (Multiple Agency Approvals)
Functional Features
- Certified Safety: Meets specific regional and international safety standards for hazardous area installations.
- Optimal Length: The 6.0-meter length provides a balance between reach and signal integrity for most standard installations.
- Signal Integrity: Precision coaxial geometry maintains consistent impedance and prevents signal loss.
Application Scenarios
Widely applied in petrochemical and power generation facilities where cables must be routed through classified hazardous areas.
Performance Parameters
- Capacitance: Matched to 3300 XL system requirements
- Operating Temperature: -51°C to +177°C
- Impedance: 50 Ohms nominal
Material Composition
Inner PTFE dielectric, braided copper shield, and outer protective jacket.
Structural Characteristics
Flexible coaxial cable with ClickLoc connectors on both ends.
Working Principle
Serves as a passive transmission line, carrying the high-frequency RF signal from the probe to the transducer without altering the signal characteristics.
Installation Requirements
Route the cable away from high-voltage power lines. Secure the cable with appropriate clamps to prevent vibration-induced fatigue.
Usage Precautions
Verify that the “-05” agency approval matches the specific hazardous area classification of the installation site. Do not kink or bend the cable beyond its minimum bend radius.
