Bently 330930‑060‑01‑05
Technical Specifications: Cable Length: 6.0 m Nominal Impedance: 75 Ω Operating Temperature Range: ‑51 °C ~ +177 °C Minimum Static Bend Radius: 22.2 mm Connector Type: Click‑Loc explosion‑proof gold‑plated self‑locking‑connector Agency Certifications: ATEX, IECEx, CSA Maximum Tensile Load: 220 N Net Weight: 790 g Compatible System: 3300 NSv proximity transducer system
Functional Features: Stainless‑steel corrugated‑armor resists mechanical‑crushing, impact and sharp‑object‑scratch. Full hazardous‑area‑certification permits deployment inside explosive‑gas‑classified‑locations. Click‑Loc explosion‑proof‑connector prevents vibration‑caused‑disconnection; tool‑free‑assembly. Full‑coaxial‑shielding suppresses industrial‑EMI‑RFI‑interference. Dual‑end CableLoc strain‑relief‑structures disperse tensile‑stress and prevent inner‑conductor‑fracture. Factory‑pre‑calibrated electrical‑matching removes on‑site‑recalibration‑work. FEP‑jacket withstands oil‑mist, dust and chemical‑pollutants.
Application Scenarios: NSv‑probe shaft‑vibration, axial‑displacement and Keyphasor‑reference‑signal‑transmission for steam‑turbines, centrifugal‑compressors, gear‑boxes in refinery‑and‑chemical‑plant hazardous‑areas. Suitable for bearing‑box‑peripheral‑wiring‑points with both mechanical‑damage‑risk and explosion‑hazard‑requirement.
Performance Parameters: Center Conductor DC Resistance: 1.32 Ω ±0.12 Ω Shield Conductor DC Resistance: 0.40 Ω ±0.08 Ω Connector Mating Cycle Life: More than 1000 insert‑extract cycles Maximum Operating Relative Humidity: 93 % non‑condensing Nominal Capacitance: 69.9 pF/m
Material Composition: Inner‑Insulation‑Layer: Fluoroethylene‑Propylene (FEP) Signal‑Conductor: High‑purity silver‑plated copper Outer‑Armor‑Layer: AISI 302 corrugated stainless‑steel Connector‑Body: Gold‑plated brass‑alloy Explosion‑proof‑Sealing‑Gasket: High‑temperature oil‑resistant fluororubber
Structural Features: 75‑Ω coaxial inner‑cable covered by corrugated stainless‑steel armor‑jacket. Both cable‑ends fitted with Click‑Loc explosion‑proof self‑locking‑circular‑connectors with built‑in‑explosion‑proof‑O‑ring‑seals. CableLoc strain‑relief‑transition‑sections molded at two‑terminals. Whole‑cable integrally‑fabricated without intermediate‑splice‑joints.
Working Principle: Passive signal‑transmission‑component with no‑signal‑conversion‑function. Fully transfers high‑frequency‑impedance‑variation‑signal generated by NSv‑probe‑coil, maintains complete‑system‑impedance‑matching, preserves gap‑voltage‑conversion‑accuracy. Armor‑layer provides mechanical‑protection; connector‑sealing‑structure fulfills hazardous‑area‑isolation‑requirement.
Installation Requirements: Follow minimum static‑bend‑radius 22.2 mm strictly, forbid forced‑sharp‑bending. Reserve adequate‑cable‑slack for equipment‑thermal‑expansion and unit‑vibration‑displacement. Separate‑routing for signal‑cable and high‑voltage‑power‑cables; forbid sharing‑one‑conduit. Confirm complete‑click‑lock‑engagement after‑connector‑mating. Ground armor‑layer independently; shielding‑layer must apply single‑end‑grounding, double‑end‑grounding‑is‑prohibited. Fasten‑cable‑segments with metal‑clamps; cable‑assembly shall‑not‑bear‑equipment‑weight. Execute‑all‑installation‑work according‑to‑local‑hazardous‑area‑installation‑codes.
Usage Notes: Forbid‑on‑site‑cutting‑truncating‑or‑splicing‑original‑factory‑cable. Sum‑length‑of‑probe‑built‑in‑cable‑plus‑extension‑cable‑must‑strictly‑match‑Proximitor‑calibrated‑total‑system‑length. Only‑operate‑on‑connector‑housing‑during‑connection‑disconnection‑procedure, never‑pull‑cable‑body‑directly. Do‑not‑replace‑original‑explosion‑proof‑connector‑with‑non‑certified‑accessories‑in‑hazardous‑area‑environment. Periodically‑inspect‑condition‑of‑connector‑sealing‑gasket.
