Description
Bently 3500 22-01-01-R0
Technical Specifications
- Module Type: Transient Data Interface (TDI)
- Hardware Revision: R0 (Base Revision)
- Network Interface: 10/100 Base-TX Ethernet
- Slot Requirement: Slot 1
Functional Features
- Version Consistency: Guarantees identical electrical characteristics and firmware compatibility with existing R0 modules in the rack.
- Baseline Performance: Provides all standard TDI communication and data capture features without later revision enhancements.
- Traceability: Allows maintenance teams to track specific production batches and factory calibration records.
Application Scenarios
Used for exact-match replacements in legacy 3500 systems,返厂维修 (return-to-factory repair) tracking, and facilities with strict hardware version control policies.
Performance Parameters
- Operating Temperature: -30°C to +65°C
- Storage Temperature: -40°C to +85°C
- Humidity: 95% non-condensing
- Data Transfer Rate: 10/100 Mbps
Material Composition
Standard industrial-grade electronic components manufactured to the original OEM R0 specifications.
Structural Characteristics
Standard full-height TDI module. The R0 designation is typically silk-screened on the internal PCB or indicated on the chassis label.
Working Principle
Captures rack data and transmits it via Ethernet, operating on the baseline firmware architecture associated with the R0 hardware.
Installation Requirements
Installed in Slot 1. Verify the R0 revision matches the system documentation before installation.
Usage Notes
If upgrading from an R0 module to a newer revision, consult Bently Nevada documentation to ensure the system firmware supports the newer hardware. Always match revisions when replacing modules in a redundant or synchronized setup.
