Description
Bently 3500/33-01-01
Technical Specifications
- Module Type: 16-Channel Relay I/O Module
- Configuration Code: 01-01 (Standard Configuration)
- Channel Count: 16 independent relay outputs
- Slot Placement: Any available monitor slot
Functional Features
- Industry Standard: The baseline high-density relay module for the 3500 platform.
- Plug-and-Play: Fully compatible with 3500 Rack Configuration Software.
- Reliable Switching: Proven performance in thousands of installations worldwide.
Application Scenarios
Standard deployment for any 3500 system requiring numerous physical relay outputs for plant DCS integration and machinery protection.
Performance Parameters
- Operating Temperature Range: -30°C to +65°C
- Storage Temperature Range: -40°C to +85°C
- Humidity: 95% non-condensing
Material Composition
Industrial-grade electronic components with environmental protection coatings.
Structural Characteristics
Full-height module with front-panel status LEDs and backplane connector.
Working Principle
Executes relay logic based on backplane signals, driving up to 16 external circuits simultaneously.
Installation Requirements
Install in any available monitor slot. Configure the correct alarm logic via the 3500 Rack Configuration Software.
Usage Notes
Verify the contact rating does not exceed the module specifications. Suppress inductive loads to prevent contact welding.
