Bently 3500/40M (176449-01 / 125680-01)
Technical Specifications
- Module Type: Enhanced 4-Channel Proximitor® I/O Module
- Front Panel PWA: 176449-01
- Rear I/O PWA: 125680-01
- Channel Count: 4 independent channels
Functional Features
- Exact Hardware Match: Guarantees identical electrical characteristics, physical dimensions, and firmware compatibility as the original module.
- Traceability: Allows maintenance teams to track production dates, firmware revisions, and factory calibration records.
- Standard Enhanced Functionality: Provides all standard M-Series vibration and position measurement capabilities.
Application Scenarios
Critical for large-scale plant maintenance, return-to-factory repair programs, and facilities with strict OEM spare parts auditing requirements.
Performance Parameters
- Operating Temperature Range: -30°C to +65°C
- Storage Temperature Range: -40°C to +85°C
- Humidity: 95% non-condensing
Material Composition
Manufactured to exact OEM specifications using high-reliability industrial components and conformal-coated PCBs.
Structural Characteristics
Standard full-height form factor. The PWA numbers are permanently marked on the internal circuit boards for verification.
Working Principle
Functions identically to the standard 3500/40M module, executing vibration measurement logic based on backplane signals.
Installation Requirements
Install in any available monitor slot. Verify the PWA numbers match the system asset register before installation.
Usage Notes
Never substitute a different PWA revision without consulting the manufacturer, as minor hardware differences can cause compatibility issues. Always provide the complete PWA combination when ordering exact replacements.
