Description
Bently 3500/42-04-00
Technical Specifications
- Module Type: 4-Channel Position Monitor Module with Safety Barrier
- Configuration Code: 04-00 (Safety Barrier, Standard Configuration)
- Channel Count: 4 independent channels
- Slot Placement: Any available monitor slot
Functional Features
- Industry Standard: The baseline safety barrier Position Monitor module for the 3500 platform.
- Plug-and-Play: Fully compatible with 3500 Rack Configuration Software without requiring special hardware jumpers.
- Reliable Measurement: Proven performance in thousands of installations worldwide for continuous position monitoring in hazardous areas.
Application Scenarios
Standard deployment for any 3500 system requiring continuous position monitoring in hazardous environments.
Performance Parameters
- Operating Temperature Range: -30°C to +65°C
- Storage Temperature Range: -40°C to +85°C
- Humidity: 95% non-condensing
Material Composition
Safety-rated industrial components with enhanced isolation and protection.
Structural Characteristics
Full-height module with safety barrier markings and standard LED indicators.
Working Principle
Processes proximity probe signals through internal safety barriers to generate position measurements in hazardous areas.
Installation Requirements
Install in an available monitor slot. Follow all hazardous area installation procedures and grounding requirements.
Usage Notes
Verify the hazardous area classification and safety barrier specifications match the application requirements.
