Description
Bently 3500/42-04-02
Technical Specifications
- Module Type: 4-Channel Position Monitor Module with Safety Barrier
- Configuration: 04-02
- Hardware Revision: 02
- Channel Count: 4 independent channels
Functional Features
- Enhanced Reliability: Incorporates improvements over the base revision.
- Backward Compatibility: Fully compatible with systems designed for the 04-00 variant.
- Updated Firmware: May include optimized signal processing algorithms.
Application Scenarios
Used as an upgraded replacement for older 04-00 modules or in new installations specifying the R02 baseline.
Performance Parameters
- Operating Temperature Range: -30°C to +65°C
- Storage Temperature Range: -40°C to +85°C
- Humidity: 95% non-condensing
Material Composition
Updated safety-rated industrial components.
Structural Characteristics
Full-height module with safety barrier markings and revision marking.
Working Principle
Operates with the enhanced 02 revision firmware, processing signals through internal safety barriers.
Installation Requirements
Install in an available monitor slot. Follow all hazardous area installation procedures.
Usage Notes
Verify system firmware compatibility before upgrading to this revision.
