Description
Bently 3500/42-09-00
Technical Specifications
- Module Type: 4-Channel Position Monitor Module
- Configuration: 09-00 (Specialized Configuration)
- Channel Count: 4 independent channels
- Slot Placement: Any available monitor slot
Functional Features
- Customized Processing: Tailored signal conditioning for specific, non-standard application requirements.
- Specialized Compatibility: Designed to integrate with unique sensor types or legacy systems.
- Core Functionality: Retains basic position measurement capabilities.
Application Scenarios
Used in highly specialized industrial applications, custom OEM machinery, or unique research and development projects.
Performance Parameters
- Operating Temperature Range: -30°C to +65°C
- Storage Temperature Range: -40°C to +85°C
- Humidity: 95% non-condensing
Material Composition
OEM-specification industrial electronics.
Structural Characteristics
Full-height module with standard LED indicators.
Working Principle
Processes proximity probe signals according to the specialized 09-00 firmware to generate position measurements.
Installation Requirements
Install in an available monitor slot. Verify configuration matches the original system design.
Usage Notes
Always verify the complete ordering code, including the “-09” variant, to ensure compatibility with the existing system. Consult the manufacturer for detailed specifications of this specialized configuration.
