Description
Bently 3500/53-02-00
Technical Specifications
- Module Type: Dual-Channel Overspeed Detection Module
- Configuration Code: 02-00 (Dual Channel)
- Channel Count: 2 independent overspeed channels
- Slot Placement: Any available monitor slot
Functional Features
- Redundant Speed Monitoring: Provides dual independent overspeed detection channels for enhanced reliability.
- High-Speed Detection: Specifically designed to detect overspeed conditions with fast response times.
- Standard Protection: Continuously compares speed values against user-programmable overspeed setpoints.
Application Scenarios
Deployed in critical steam turbines, gas turbines, and compressors where redundant overspeed protection is required for safety-critical applications.
Performance Parameters
- Operating Temperature Range: -30°C to +65°C
- Storage Temperature Range: -40°C to +85°C
- Humidity Tolerance: 95% non-condensing
Material Composition
Industrial-grade electronic components with environmental protection coatings.
Structural Characteristics
Full-height module with front-panel LED indicators for channel status and module health.
Working Principle
Receives speed signals from two independent sensors, processes them for overspeed detection, and triggers alarms when configured thresholds are exceeded.
Installation Requirements
Install in an available monitor slot. Connect two independent speed sensor cables.
Usage Notes
Configure both channels independently in the 3500 Rack Configuration Software. Verify both channels are functioning correctly after installation.
