Description
Bently 3500/54-01-00AM
Technical Specifications
- Module Type: Electronic Overspeed Protection Module
- Configuration Code: 01-00AM (Standard with Agency Approvals)
- Channel Count: Configurable for redundant protection
- Slot Placement: Any available monitor slot
Functional Features
- Independent Protection: Provides dedicated overspeed protection independent of other monitoring functions.
- High-Integrity Design: Engineered to meet stringent safety requirements for overspeed protection.
- Agency Compliance: Certified to meet specific regional or international safety standards.
Application Scenarios
Deployed in critical steam turbines, gas turbines, and compressors where independent, high-integrity overspeed protection is required.
Performance Parameters
- Operating Temperature Range: -30°C to +65°C
- Storage Temperature Range: -40°C to +85°C
- Humidity Tolerance: 95% non-condensing
Material Composition
Safety-rated industrial components with enhanced reliability testing.
Structural Characteristics
Full-height module with front-panel LED indicators for operational status and fault diagnostics.
Working Principle
Receives speed signals from dedicated sensors, processes them for overspeed detection, and triggers protective relays when configured thresholds are exceeded.
Installation Requirements
Install in an available monitor slot. Follow all safety system installation procedures.
Usage Notes
Verify the agency approvals match the application requirements. Do not substitute with non-approved modules in safety-critical applications.
