Bently 3500/54M-01-00
Technical Specifications
- Module Type: Gas Turbine Vibration Monitor
- Configuration: 01-00
- Application Focus: Gas Turbine Engines
- System Integration: 3500 Machinery Protection System
Functional Features
- Gas Turbine Specific Algorithms: Tailored signal processing to handle the unique vibration signatures and high-speed dynamics of gas turbines.
- High-Speed Processing: Capable of capturing rapid transient events during turbine startup, shutdown, and load changes.
- Comprehensive Protection: Monitors critical parameters to prevent catastrophic mechanical failure.
Application Scenarios
Exclusively deployed in power generation and oil & gas facilities utilizing heavy-duty or aeroderivative gas turbines.
Performance Parameters
- Measurement Accuracy: High-resolution digital signal processing
- Dynamic Range: Wide bandwidth for high-speed turbine monitoring
- Operating Temperature: -30°C to +65°C
Material Composition
Industrial-grade electronic components, conformal-coated PCBs, and a ruggedized metallic shielding enclosure.
Structural Characteristics
Standard full-height 3500 rack module with front-panel status LEDs and rear high-density backplane connectors.
Working Principle
Processes specialized sensor inputs using gas turbine-specific algorithms to extract accurate vibration and position data.
Installation Requirements
Must be installed in an available slot within a 3500 rack. Ensure the backplane connector is fully seated and secure the front panel mounting screws.
Usage Precautions
Always use the 3500 Rack Configuration Software to verify channel parameters after installation. Never remove or insert the module while the rack power is energized to prevent backplane damage.
