Bently Nevada 3301-03-08-00-02
Technical Specifications
- Model: 3301-03-08-00-02
- Series: 3300 Series (pre-XL generation)
- Thread Type: M10 x 1 metric thread
- Case Length: 80 mm
- Unthreaded Length: 0 mm
- Cable Length and Option: 02 configuration
- Probe Diameter: 8 mm
- Linear Range: 2.0 mm (80 mils)
- Scale Factor: 7.87 V/mm (200 mV/mil)
- Frequency Response: 0 Hz to 10 kHz
- Operating Temperature: -51°C to +177°C
Function Features
- Eddy current non-contact sensing technology
- Direct measurement of shaft vibration and position
- Compatible with 3300 series Proximitor sensors
- Static and dynamic measurement modes
- Voltage output proportional to gap distance
- Field-proven reliability in industrial environments
Application Scenarios
- Turbine vibration monitoring installations
- Compressor shaft position tracking
- Pump and fan bearing condition assessment
- Rotating machinery protection systems
- Industrial predictive maintenance programs
Performance Parameters
- Scale factor is 7.87 V/mm (200 mV/mil)
- Linear range is 2.0 mm
- Target material is AISI 4140 steel (standard calibration)
- Frequency response is DC to 10 kHz
- Gap voltage range is -2 VDC to -18 VDC
Material Composition
- Probe case is stainless steel
- Probe tip is engineered polymer
- Cable is coaxial with FEP insulation
- Connector is standard coaxial type
Structural Characteristics
- 80 mm case length for deep mounting applications
- M10 x 1 metric mounting thread
- Integral cable with probe body
- Coaxial connector for system integration
- Rugged construction for industrial environments
Working Principle The probe operates using eddy current technology. The probe coil, energized by the Proximitor sensor, creates an electromagnetic field at the probe tip. When a conductive target is present, circulating eddy currents are generated in the target material. The Proximitor sensor detects the resulting impedance change and generates a DC voltage output that varies linearly with the distance between probe tip and target surface.
Installation Requirements
- Mount in M10 x 1 threaded hole of appropriate depth
- Maintain perpendicular orientation to target surface
- Set initial gap voltage within linear range
- Secure with locknut to prevent loosening
- Connect to compatible 3300 series extension cable and Proximitor sensor
Operating Considerations
- Use with matching 3300 series system components
- Verify target material matches calibration standard
- Avoid probe-to-shaft contact during operation
- Inspect cable and connector condition regularly
- Replace if probe tip shows wear or damage
