Description
Bently Nevada 3301-30-085-00-05
Technical Specifications
- Model: 3301-30-085-00-05
- Series: 3300 XL Proximity Transducer System
- Cable Length: 8.5 meters (27.9 feet)
- Connector Protector and Cable Option: 00 — Standard cable
- Agency Approval: 05 — Multiple approvals (CSA, ATEX, IECEx)
- Cable Construction: 75 Ω triaxial, Fluorinated Ethylene Propylene (FEP) insulated
- Capacitance: 69.9 pF/m (21.3 pF/ft) typical
- Operating Temperature: -52°C to +177°C (-62°F to +350°F)
- Weight: 0.289 kg (0.64 lbs)
- Connector Type: Gold-plated ClickLoc miniature coaxial connectors
Function Features
- Standard cable construction for general industrial applications
- Multiple hazardous area certifications for global deployment
- Gold-plated ClickLoc connectors for secure electrical contact
- Complete interchangeability within 3300 XL system
- Backward compatibility with non-XL 3300 series components
- Reliable signal transmission for vibration and position monitoring
Application Scenarios
- Fluid-film bearing machine monitoring in hazardous areas
- Turbine and compressor vibration monitoring
- Shaft position measurement systems
- Keyphasor signal transmission
- Power generation and petrochemical industry applications
Performance Parameters
- Extension cable capacitance is 69.9 pF/m typical
- System linear range is 2.0 mm (80 mils) when paired with 8 mm probe
- Scale factor is 7.87 V/mm (200 mV/mil)
- Frequency response is 0 Hz to 10 kHz
- Power supply sensitivity is less than 2 mV per volt change
Material Composition
- Cable jacket is Fluorinated Ethylene Propylene (FEP)
- Conductors are copper with controlled impedance
- Connectors are gold-plated brass or beryllium copper
- Shielding is triaxial construction
Structural Characteristics
- Standard non-armored flexible cable
- Triaxial design for EMI/RFI immunity
- ClickLoc gold-plated connectors
- Compact and lightweight construction
- Suitable for conduit routing
Installation Requirements
- Verify combined probe and cable length matches Proximitor calibration
- Install with minimum bend radius of 25.4 mm
- Secure cable along routing path to prevent strain
- Separate from high-voltage cables to prevent interference
- Verify proper ClickLoc connector engagement
Operating Considerations
- Suitable for hazardous areas with CSA, ATEX, and IECEx approvals
- Maximum field wiring length between Proximitor sensor and monitor is 305 meters
- Inspect cable condition during routine maintenance
- Replace if insulation damage is detected
- Maintain connector cleanliness for optimal signal transmission
