Bently Nevada 330103-040-00-00
Technical Specifications
- Model: 330103-040-00-00
- Probe Series: 3300 XL 8 mm
- Thread Type: M10 x 1 metric thread
- Overall Case Length: 40 mm
- Unthreaded Length: 0 mm
- Total Cable Length: 1.0 meter
- Connector and Cable Option: Standard cable
- Agency Approval: 00
- Linear Range: 2.0 mm (80 mils)
- Scale Factor: 7.87 V/mm (200 mV/mil)
- Frequency Response: 0 Hz to 10 kHz
- Operating Temperature: -51°C to +177°C
- Weight: 0.423 kg
Function Features
- High-precision non-contact displacement measurement
- Patented TipLoc molding technology for enhanced probe tip durability
- CableLoc design ensuring 330 N cable pull strength
- Complete interchangeability within 3300 XL system
- Backward compatibility with non-XL 3300 series components
- Suitable for both static position and dynamic vibration measurements
Application Scenarios
- Steam turbine radial vibration monitoring
- Gas turbine axial position measurement
- Centrifugal compressor shaft displacement tracking
- Large industrial pump bearing condition assessment
- Generator rotor position monitoring
Performance Parameters
- Incremental scale factor is 7.87 V/mm (200 mV/mil) ±5% for standard 5m system
- Linear range is 2.0 mm starting from 0.25 mm gap
- Recommended operating gap is -9 VDC
- Temperature stability maintains accuracy across full temperature range
- Frequency response flatness is 0 Hz to 10 kHz
Material Composition
- Probe tip material is Polyphenylene sulfide (PPS)
- Probe case material is AISI 303 or 304 stainless steel
- Cable jacket is Fluorinated Ethylene Propylene (FEP)
- Connector contacts are gold-plated brass or beryllium copper
Structural Characteristics
- Smooth cylindrical stainless steel case
- M10 x 1 metric mounting thread with standard locknut
- Integral cable with strain relief at probe body
- Miniature coaxial connector for extension cable attachment
- Compact design for installations with limited space
Working Principle The probe generates a high-frequency electromagnetic field at its tip. When positioned near a conductive target surface, eddy currents are induced in the target. The resulting energy loss modifies the probe coil impedance. The Proximitor sensor detects this impedance change and produces an output voltage directly proportional to the physical gap between probe tip and target surface.
Installation Requirements
- Install in properly tapped M10 x 1 threaded hole
- Maintain target surface perpendicularity within 2 degrees
- Set gap voltage to -9 VDC using target material
- Secure locknut to prevent probe loosening from vibration
- Route cable to avoid contact with hot surfaces or sharp edges
Operating Considerations
- Target surface must be clean, smooth, and conductive
- Avoid installing probe beyond linear range limits
- Do not allow probe tip to contact rotating shaft
- Inspect cable integrity during routine maintenance
- Replace probe if tip damage or cable fraying is observed
