Description
Bently Nevada 330130-010-03-00
Technical Specifications
- Model: 330130-010-03-00
- Series: 3300 XL Proximity Transducer System
- Cable Length: 1.0 meter (3.3 feet)
- Connector Protector and Cable Option: 03 (armored cable)
- Agency Approval: 00
- Capacitance: 69.9 pF/m (21.3 pF/ft) typical
- Operating Temperature: -52°C to +177°C (-62°F to +350°F)
- Connector Material: Gold-plated brass or gold-plated beryllium copper
- Weight: 34 g/m (0.4 oz/ft)
Function Features
- Signal transmission between probe and Proximitor sensor
- Armored cable construction for mechanical protection
- Gold-plated ClickLoc connectors for secure connection
- Complete interchangeability with 3300 XL system components
- Backward compatibility with non-XL 3300 series 5mm and 8mm components
- Maintains system accuracy and linearity
Application Scenarios
- Fluid-film bearing machine monitoring
- Steam and gas turbine protection systems
- Centrifugal compressor condition monitoring
- Keyphasor and speed measurement systems
- Industrial rotating machinery vibration monitoring
Performance Parameters
- Extension cable capacitance is 69.9 pF/m typical
- Signal integrity is maintained over full cable length
- Pull strength is 330 N with CableLoc technology
- Impedance is matched to 3300 XL system requirements
- Temperature stability provides full performance across operating range
Material Composition
- Cable jacket is Fluorinated Ethylene Propylene (FEP) with armor
- Armor is flexible AISI 302 stainless steel with FEP outer jacket
- Conductors are copper with precision impedance control
- Connectors are gold-plated brass or beryllium copper
Structural Characteristics
- Armored construction for enhanced mechanical protection
- Triaxial cable design
- ClickLoc connectors at both ends
- Connector protector on female end
- Flexible armor for routing in industrial environments
Installation Requirements
- Ensure total system length matches Proximitor sensor calibration
- Route cable with minimum 25.4 mm bend radius
- Secure cable to prevent strain on connectors
- Maintain separation from high-voltage cables
- Verify ClickLoc connectors are fully engaged
Operating Considerations
- Do not exceed maximum system length for matched Proximitor sensor
- Inspect armor for damage that could compromise protection
- Verify connector tightness during maintenance rounds
- Replace if cable jacket or armor shows excessive wear
- Ensure proper mating of gold-plated connectors
