Description
Bently Nevada 330130-030-02-00
Technical Specifications
- Model: 330130-030-02-00
- Series: 3300 XL Proximity Transducer System
- Cable Length: 3.0 meters (9.8 feet)
- Connector Protector and Cable Option: 02 (standard cable with connector protector)
- Agency Approval: 00
- Capacitance: 69.9 pF/m (21.3 pF/ft) typical
- Operating Temperature: -52°C to +177°C (-62°F to +350°F)
- Connector Material: Gold-plated brass or gold-plated beryllium copper
- Weight: 34 g/m (0.4 oz/ft)
Function Features
- Signal transmission with connector protection
- Gold-plated ClickLoc connectors for corrosion resistance
- Connector protector prevents liquid ingress into connections
- Complete interchangeability within 3300 XL system
- Backward compatibility with non-XL components
- Maintains full system accuracy and linearity
Application Scenarios
- Machinery monitoring in oil-saturated environments
- Turbine and compressor vibration monitoring
- Shaft position measurement systems
- Keyphasor signal transmission
- Industrial rotating equipment protection
Performance Parameters
- Cable capacitance is 69.9 pF/m typical
- Signal attenuation is negligible over 3.0 meter length
- Connector durability is provided by gold-plated contacts
- Temperature coefficient is stable across full range
- Impedance matching is optimized for 3300 XL system
Material Composition
- Cable jacket is Fluorinated Ethylene Propylene (FEP)
- Connector protector is fluorosilicone material
- Conductors are copper with controlled impedance
- Connectors are gold-plated brass or beryllium copper
Structural Characteristics
- Standard cable with connector protector on female end
- Triaxial construction
- ClickLoc connector system
- Flexible cable for industrial routing
- Protected connector interface
Installation Requirements
- Match total system length to Proximitor sensor calibration
- Maintain minimum 25.4 mm bend radius
- Route cable to prevent mechanical damage
- Ensure connector protector is properly seated
- Verify finger-tight connection of ClickLoc connectors
Operating Considerations
- Connector protector helps prevent oil and moisture ingress
- Inspect protector condition during maintenance
- Replace if cable shows signs of wear or damage
- Ensure connectors are clean before mating
- Do not over-tighten connectors beyond finger-tight
