Description
Bently Nevada 330130-085-01-0
Technical Specifications
- Model: 330130-085-01-0 (equivalent to 330130-085-01-00)
- Series: 3300 XL Proximity Transducer System
- Cable Length: 8.5 meters (27.9 feet)
- Connector Protector and Cable Option: 01 — Armored cable
- Agency Approval: 0 — Not required (truncated from 00)
- Cable Construction: 75 Ω triaxial, Fluorinated Ethylene Propylene (FEP) insulated with armor
- Capacitance: 69.9 pF/m (21.3 pF/ft) typical
- Operating Temperature: -51°C to +177°C (-60°F to +350°F)
- Weight: Approximately 0.948 kg
- Connector Type: Gold-plated ClickLoc miniature coaxial connectors
Function Features
- Armored construction provides enhanced mechanical protection
- Gold-plated ClickLoc connectors for corrosion resistance
- Complete interchangeability with 3300 XL system components
- Backward compatibility with non-XL 3300 series transducers
- Maintains full system accuracy and linearity
- Suitable for harsh industrial environments
Application Scenarios
- Machinery monitoring in physically demanding environments
- Turbine and compressor vibration monitoring
- Shaft position measurement in heavy industry
- Keyphasor reference signal routing
- Applications requiring cable protection from mechanical damage
Performance Parameters
- Cable capacitance is 69.9 pF/m typical
- Impedance is 75 Ω matched to system requirements
- Signal integrity is maintained over full cable length
- Armored construction adds durability without compromising flexibility
- Temperature stability provides consistent performance across range
Material Composition
- Cable jacket is Fluorinated Ethylene Propylene (FEP) with armor
- Armor is flexible AISI 302 stainless steel with FEP outer jacket
- Conductors are copper with precision impedance control
- Connectors are gold-plated brass or beryllium copper
Structural Characteristics
- Armored construction for enhanced mechanical protection
- Triaxial cable design
- ClickLoc connectors at both ends
- Flexible armor for routing in industrial environments
- Robust construction for crush and abrasion resistance
Installation Requirements
- Ensure total system length matches Proximitor sensor calibration
- Route cable with minimum 25.4 mm bend radius
- Secure cable to prevent strain on connectors
- Maintain separation from high-voltage cables
- Verify ClickLoc connectors are fully engaged
Operating Considerations
- Do not exceed maximum system length for matched Proximitor sensor
- Inspect armor for damage that could compromise protection
- Verify connector tightness during maintenance rounds
- Replace if cable jacket or armor shows excessive wear
- Ensure proper mating of gold-plated connectors
