Bently Nevada 330130-085-13-00
Technical Specifications
- Model: 330130-085-13-00
- Series: 3300 XL Proximity Transducer System
- Cable Length: 8.5 meters (27.9 feet)
- Connector Protector and Cable Option: 13 — Armored FluidLoc cable with connector protector
- Agency Approval: 00 — Not required
- Cable Construction: 75 Ω triaxial, Fluorinated Ethylene Propylene (FEP) insulated with armor
- Capacitance: 69.9 pF/m (21.3 pF/ft) typical
- Operating Temperature: -51°C to +177°C (-60°F to +350°F)
- Weight: Approximately 0.82 kg
- Connector Type: Gold-plated ClickLoc miniature coaxial connectors with protectors
Function Features
- Armored construction provides superior mechanical protection
- FluidLoc design prevents oil and liquid leakage
- Connector protectors enhance environmental sealing
- Gold-plated ClickLoc connectors for corrosion resistance
- Complete interchangeability within 3300 XL system
- Maximum durability for harsh industrial conditions
Application Scenarios
- Critical machinery in physically demanding and oily environments
- Turbine bearing housings requiring armor and fluid sealing
- Compressor applications with high vibration and oil exposure
- Heavy industrial rotating equipment monitoring
- Applications requiring maximum cable protection
Performance Parameters
- Extension cable capacitance is 69.9 pF/m typical
- Impedance is 75 Ω matched to system requirements
- Signal fidelity is maintained despite armor addition
- Temperature stability across full operating range
- Crush resistance from stainless steel armor
Material Composition
- Cable jacket is Fluorinated Ethylene Propylene (FEP)
- Armor is flexible AISI 302 stainless steel
- FluidLoc sealant prevents liquid migration
- Conductors are copper with precision impedance control
- Connectors are gold-plated brass or beryllium copper
Structural Characteristics
- Armored FluidLoc cable with connector protector
- Triaxial construction for signal integrity
- ClickLoc connector system
- Crush-resistant and fluid-sealed design
- Flexible armor for industrial routing
Installation Requirements
- Ensure total system length matches Proximitor sensor calibration
- Install with minimum 25.4 mm bend radius
- Secure cable to prevent strain on connectors
- Maintain separation from high-voltage cables
- Verify ClickLoc connectors are fully engaged
Operating Considerations
- Inspect armor and FluidLoc seal during maintenance
- Verify connector protectors are properly seated
- Replace if armor shows damage or fluid migration occurs
- Keep connectors clean and dry
- Do not over-tighten connectors beyond finger-tight
