Description
Bently Nevada 330130-085-13-05
Technical Specifications
- Model: 330130-085-13-05
- Series: 3300 XL Proximity Transducer System
- Cable Length: 8.5 meters (27.9 feet)
- Connector Protector and Cable Option: 13 — Armored FluidLoc cable with connector protector
- Agency Approval: 05 — Multiple approvals (CSA, ATEX, IECEx)
- Cable Construction: 75 Ω triaxial, Fluorinated Ethylene Propylene (FEP) insulated with armor
- Capacitance: 69.9 pF/m (21.3 pF/ft) typical
- Operating Temperature: -51°C to +177°C (-60°F to +350°F)
- Weight: 0.82 kg (Approx. 1.81 lbs)
- Connector Type: Gold-plated ClickLoc miniature coaxial connectors with protectors
Function Features
- Armored construction provides maximum mechanical protection
- FluidLoc design prevents oil and liquid migration
- Connector protectors enhance environmental sealing
- Multiple hazardous area certifications for global deployment
- Gold-plated ClickLoc connectors for corrosion resistance
- Complete interchangeability with 3300 XL system components
Application Scenarios
- Critical turbine supervisory instrumentation in hazardous areas
- Pipeline compression with oil exposure and explosion risk
- Power generation in explosive atmospheres
- Chemical and petrochemical processing
- Heavy industry requiring maximum cable protection
Performance Parameters
- Extension cable capacitance is 69.9 pF/m typical
- Impedance is 75 Ω maintained over full length
- Signal integrity preserved through armor and seal
- Temperature stability across full operating range
- Intrinsically safe for hazardous area deployment
Material Composition
- Cable jacket is Fluorinated Ethylene Propylene (FEP)
- Armor is flexible AISI 302 stainless steel
- FluidLoc sealant prevents liquid ingress
- Conductors are copper with controlled impedance
- Connectors are gold-plated brass or beryllium copper
Structural Characteristics
- Armored FluidLoc cable with connector protector
- Triaxial shielded design
- ClickLoc gold-plated connectors
- Maximum protection construction
- Flexible armor for industrial installation
Installation Requirements
- Ensure combined probe and cable length matches Proximitor calibration
- Install with minimum 25.4 mm bend radius
- Route through dedicated conduit where required
- Ensure connector protectors are properly seated
- Verify proper ClickLoc connector engagement
Operating Considerations
- Suitable for hazardous areas with CSA, ATEX, and IECEx approvals
- Inspect armor and seal integrity during routine maintenance
- Replace if armor damage or fluid migration is detected
- Keep connectors clean before mating
- Maintain connector protector seating for environmental protection
