Product Overview: The 330930-040-00-05 is an extension cable within the Bently Nevada 3300 NSv (Non-Standard vibration) eddy current sensor system. The 3300 NSv system is designed for small target applications, providing high sensitivity in compact installations. In the model number, “330930” designates the 3300 NSv extension cable product base, “040” indicates a cable length of 4.0 meters, “00” denotes a standard non-armored cable, and “05” indicates multi-agency approval (CSA NRTL/C, BASEEFA/CENELEC, CSA Division 2). This cable is fully compatible with 3300 XL NSv proximity probes and corresponding Proximitor transducers.

Request Quote
Category:

Description

Bently Nevada 330930-040-00-05

Technical Specifications:

  • Cable Length: 4.0 meters
  • Cable Type: Standard non-armored cable
  • Probe System: 3300 XL NSv
  • Connector Type: ClickLoc gold-plated copper connectors
  • Conductor Type: 75Ω triaxial coaxial structure
  • Insulation Material: FEP (Fluoroethylene Propylene)
  • Operating Temperature Range: -52°C to +177°C
  • Minimum Bend Radius: 25.4mm (1 inch)
  • Certification: CSA NRTL/C, BASEEFA/CENELEC, CSA Division 2
  • Compliance Standard: API 670 (4th Edition)

Functional Features:

  • Designed specifically for the 3300 NSv proximity probe system
  • Multi-agency certification supports hazardous area (Division 2) installations
  • 75Ω triaxial coaxial structure ensures impedance matching and signal transmission integrity
  • FEP insulation material provides excellent chemical resistance and high-temperature performance
  • Multi-layer shielding design effectively resists electromagnetic interference in the field
  • ClickLoc gold-plated copper connectors ensure corrosion-resistant, tool-free reliable connections
  • Fully interchangeable within the 3300 NSv system
  • Low-loss high-frequency signal transmission

Application Scenarios:

  • Centrifugal air compressor vibration monitoring
  • Small pump and fan shaft vibration monitoring
  • Motor bearing vibration monitoring
  • Applications with limited installation space requiring compact probe systems
  • Hazardous area installations requiring multi-agency certification
  • General-purpose rotating machinery condition monitoring in classified zones

Performance Parameters:

  • Cable Capacitance: 69.9 pF/m (21.3 pF/ft)
  • Output Impedance: 50Ω
  • Sensitivity Stability: Output changes less than 2mV per 1 volt change in input voltage
  • Frequency Response: 0 to 10kHz
  • Linear Range (with NSv probe): 1.5mm
  • Sensitivity (with NSv probe): 7.87 V/mm (200 mV/mil)

Material Composition:

  • Conductor: Copper core with braided shielding layer
  • Insulation Layer: FEP (Fluoroethylene Propylene)
  • Connector: ClickLoc gold-plated copper
  • Outer Jacket: Standard industrial-grade polymer

Structural Characteristics: Flexible coaxial cable with a triaxial structure. The cable is equipped with ClickLoc gold-plated copper connectors. The standard non-armored structure is lightweight and flexible, suitable for routing through conduit or cable trays. The 4.0-meter length is suitable for 5-meter system configurations (when paired with a 1-meter probe cable) or for specific installation requirements.

Working Principle: The extension cable serves as the signal transmission bridge in the eddy current sensor system, transmitting the high-frequency signal generated by the probe tip coil to the Proximitor without loss through the coaxial structure. The outer shielding braid of the coaxial structure prevents external electromagnetic interference from intruding, while the inner signal line maintains constant impedance. Once the signal reaches the Proximitor, it undergoes amplification, demodulation, and linearization, ultimately outputting a DC voltage signal proportional to the distance between the probe tip and the target surface.

Installation Requirements:

  • Ensure the total length of the probe cable plus the extension cable strictly equals 5.0 meters or 7.0 meters (NSv system lengths)
  • Cable routing must maintain at least 30cm clearance from high-voltage power cables
  • Maintain a minimum bend radius of 25.4mm; prohibit excessive bending
  • ClickLoc connectors are hand-tightened; do not use tools
  • The shielding layer must be grounded at a single point on the Proximitor end; prohibit multi-point grounding to prevent ground loops
  • Hazardous area installations must comply with applicable explosion-proof regulations

Usage Notes:

  • The “00” code indicates a standard non-armored cable, suitable for clean indoor environments
  • The “05” code indicates multi-agency certification; verify that the specific certifications meet site requirements before installation
  • Inspect connector condition at each maintenance interval
  • Never cut or splice the extension cable; any modification will destroy impedance matching
  • The NSv system cable is not interchangeable with 8mm or 11mm system cables; ensure correct system matching
  • When replacing the cable, select a specification that exactly matches the original model
