Description
B&R 5AP1120.0702-000
Technical Specifications:
- Brand: B&R Industrial Automation
- Model: 5AP1120.0702-000
- Product Type: All-in-One Automation Panel
- Display: High-resolution TFT touchscreen
Functional Features:
- Integrated Control: Combines visualization and logic execution in one device, reducing panel footprint and wiring complexity.
- High-Speed Processing: Equipped with robust processing power to handle complex motion control and visualization tasks simultaneously.
- Industrial Connectivity: Features multiple communication ports for seamless integration with distributed I/O and drive systems.
Application Scenarios:
Widely used as the primary operator interface and controller in packaging machinery, textile equipment, and automated manufacturing cells.
Performance Parameters:
- Touch Response: Fast and accurate touch response for precise operator input.
- Processing Speed: Optimized for real-time industrial control and high-refresh-rate graphics.
Material Composition:
Front panel constructed from durable, chemical-resistant glass. Rear housing is made of high-impact, flame-retardant metal.
Structural Features:
Ergonomic, bezel-less design with standard cutout dimensions for easy panel integration. Features side or rear-mounted I/O connectors.
Working Principle:
Runs advanced visualization and control software (e.g., B&R Automation Studio) to render graphical interfaces, process touch inputs, and execute real-time control logic via its integrated CPU.
Installation Requirements:
Mount securely into a standard rectangular panel cutout using the provided mounting brackets. Ensure adequate rear clearance for heat dissipation.
Usage Precautions:
Clean the touchscreen only with approved, non-abrasive cleaning agents. Avoid exposing the panel to direct, high-intensity sunlight or excessive mechanical shock.
