Description
B&R 8LSA75.E1022D200-0
Technical Specifications:
- Brand: B&R Industrial Automation
- Model: 8LSA75.E1022D200-0
- Product Type: Synchronous Motor
- Rated Speed: 1500 to 4500 rpm
- Stall Torque: 26 to 85 Nm
- Flange Size: 190 x 190 mm
Functional Features:
- Extreme Torque Output: Delivers up to 85 Nm of stall torque for the most demanding industrial processes.
- Reinforced Bearings: Equipped with heavy-duty bearings to support high mechanical loads and extend service life.
- Dynamic Precision: Maintains excellent controllability and low torque ripple despite its massive power output.
- Versatile Cooling: Available in multiple cooling configurations to match specific thermal management needs.
Application Scenarios:
Designed for large-scale manufacturing equipment, heavy material handling, steel rolling mills, and high-capacity injection molding machines.
Performance Parameters:
- Center Diameter: 180j6 mm
- Shaft Diameter: 38k6 mm (with reinforced bearing option: 42k6 mm)
- Speed Range: Optimized for high-torque applications at lower base speeds (1500 rpm).
Material Composition:
Constructed with premium magnetic steel, heavy-duty cast iron or aluminum housing, and industrial-grade insulation systems for maximum thermal and mechanical endurance.
Structural Characteristics:
Features a large 190 x 190 mm flange and a robust 38k6 mm shaft. The design prioritizes structural rigidity to handle extreme torque without deflection.
Working Principle:
Operates as a high-power synchronous motor, utilizing advanced winding techniques and high-energy permanent magnets to convert electrical power into massive mechanical torque with high efficiency.
Installation Requirements:
Requires a rigid mounting surface due to the high torque output. Ensure precise shaft alignment using the 38k6 mm or 42k6 mm reinforced shaft.
Usage Precautions:
Do not exceed the maximum stall torque rating. Regularly inspect the reinforced bearings and ensure the cooling system (if applicable) is functioning optimally.
