ELAU C400-10-1-1-1-0
Technical Specifications:
- Brand: ELAU (Schneider Electric)
- Model: C400-10-1-1-1-0
- Product Type: Motion Controller
- Power Supply: 24V DC.
- Expansion: Slots for interface modules.
- Protection: IP20.
Functional Features:
- Distributed Control: Optimized for controlling drives over Sercos or EtherCAT.
- Logic Control: Full PLC functionality compliant with IEC 61131-3.
- HMI Integration: Easy connection to operator panels.
Application Scenarios:
- Textile machinery.
- Paper converting.
- Automated warehousing.
Performance Parameters:
- Synchronization: Jitter-free synchronization of axes.
- Response Time: Deterministic response for critical control loops.
Material Composition:
- Industrial grade thermoplastics and metals.
Structural Features:
- Compact form factor.
- Clear labeling of terminals and ports.
Working Principle:
The controller reads inputs, executes the control algorithm (PLC logic + Motion planning), and updates outputs. It communicates with servo drives to regulate motor torque and speed based on the calculated trajectory.
The controller reads inputs, executes the control algorithm (PLC logic + Motion planning), and updates outputs. It communicates with servo drives to regulate motor torque and speed based on the calculated trajectory.
Installation Requirements:
- Install in a control cabinet free from conductive dust.
- Maintain separation between power cables and signal cables.
Usage Notes:
- Ensure the “10” interface module (if applicable) matches the required fieldbus.
- Verify the power supply polarity.
