Description
ELAU MAX-4-11-03-128-99-1-1-00
Technical Specifications:
- Brand: ELAU (Schneider Electric)
- Model: MAX-4-11-03-128-99-1-1-00
- Product Type: Servo Drive
- Output Current: 3A
- Supply Voltage: 24V (Control), Main power varies
- Rated Power: 128W
- Peak Power: 256W
- Dimensions: 100 x 225 x 190 mm
- Weight: 3.9 kg
- Protection Class: IP20
Functional Features:
- Control Modes: Supports Position, Speed, and Torque control.
- Communication: EtherCAT, CANopen, Profibus DP.
- Modular Design: Easy to expand and maintain.
- High Reliability: Designed for harsh industrial environments.
Application Scenarios:
- Automotive manufacturing (assembly lines, welding).
- Electronics manufacturing (SMT pick and place).
- Food and beverage packaging.
- Logistics and sorting systems.
Performance Parameters:
- Rated Torque: 2.8 Nm
- Peak Torque: 5.6 Nm
- Rated Speed: 3000 rpm
- Max Speed: 6000 rpm
- Control Precision: ±0.01°
Material Composition:
- Industrial grade thermoplastics and metals.
- High-quality electronic components.
Structural Features:
- DIN rail mounting.
- Plug-in connectors for power and I/O.
- Status LEDs.
Working Principle:
The drive converts control signals into drive currents for the servo motor. It uses feedback from the motor encoder to perform closed-loop control, ensuring accurate torque, speed, and position regulation.
Installation Requirements:
- Mount on a standard 35mm DIN rail.
- Ensure adequate ventilation for heat dissipation.
- Connect shielding cables properly to minimize EMI.
Usage Notes:
- Verify the voltage rating matches the power supply.
- Ensure the connected motor is compatible with the drive’s current rating.
- Use the provided software tools for parameter configuration.
