Description
ELAU PMC-2-11-05-000-01-00-06-00-0K
Technical Specifications:
- Brand: ELAU (Schneider Electric)
- Model: PMC-2-11-05-000-01-00-06-00-0K
- Series: PMC-2
- Processor: 32-bit architecture with VECON chip
- Interface: Digital and Analog I/O
Functional Features:
- Unified Software: One software environment for both positioning and synchronization programs.
- Electronic Gearing: Supports electronic gear and cam functions for complex motion profiles.
- Diagnostic Tools: Mature diagnostic capabilities for troubleshooting and maintenance.
- Encoder Support: Compatible with both absolute and incremental encoders.
Application Scenarios:
- Printing and converting equipment.
- Textile machinery.
- CNC machine tools.
Performance Parameters:
- Control Precision: High-precision closed-loop control.
- Overload Capacity: High overload capability for short durations.
- Communication: Supports cross-connection capabilities for multi-axis systems.
Material Composition:
- Robust industrial housing.
- Advanced semiconductor components.
Structural Features:
- Standard flange or DIN rail mounting options.
- Shielded connectors for EMC compliance.
Working Principle:
The unit operates by receiving setpoints from a higher-level controller or internal program. It calculates the required torque and current, then drives the connected servo motor. The feedback loop continuously adjusts the output to minimize error between the actual and target position.
Installation Requirements:
- Install in a clean, dry environment.
- Maintain separation between power cables and signal cables to reduce interference.
- Ensure the cooling airflow is not obstructed.
Usage Notes:
- Check the specific firmware version for feature compatibility.
- Do not exceed the maximum permissible ambient temperature.
- Use shielded cables for all encoder connections.
