ELAU SB105-30-06-05-19-S-01-64-EAKN
Technical Specifications:
- Brand: ELAU (Schneider Electric)
- Model: SB105-30-06-05-19-S-01-64-EAKN
- Series: SB105
- Flange Size: 105 mm
- Rated Speed: 3000 RPM (typical for this series)
- Protection Class: IP65 / IP67 (depending on specific sealing)
Functional Features:
- High Dynamic Response: Optimized for fast acceleration and deceleration.
- Integrated Feedback: Equipped with a high-resolution encoder for precise closed-loop control.
- Robust Construction: Designed to withstand harsh industrial environments.
- Single Cable Technology: Simplifies installation and reduces wiring errors.
Application Scenarios:
- High-speed packaging machinery.
- Robotics and handling systems.
- Printing and converting equipment.
Performance Parameters:
- Torque: High torque density for compact applications.
- Control Modes: Position, Velocity, and Torque control.
- Efficiency: High energy efficiency due to permanent magnet design.
Material Composition:
- Housing: Industrial-grade aluminum with epoxy coating.
- Magnets: Neodymium Iron Boron (NdFeB) permanent magnets.
Structural Features:
- Compact flange mounting design.
- IP65/IP67 rated connectors.
- Self-cooling design for continuous operation.
Working Principle:
The motor operates as a synchronous AC servo motor. The drive supplies three-phase current to the stator windings, creating a rotating magnetic field that interacts with the permanent magnets on the rotor. The integrated encoder provides real-time position feedback to the drive, ensuring precise motion control.
Installation Requirements:
- Mount securely on a rigid surface using the standard flange.
- Ensure proper alignment of the shaft to avoid mechanical stress.
- Connect the power and feedback cables using shielded connectors.
Usage Notes:
- Verify the voltage rating matches the connected drive.
- Do not exceed the permissible radial and axial loads on the shaft.
- Ensure adequate ventilation for heat dissipation.
