ELAU SH-140-30270-0-1-00-00-00-10-03
Technical Specifications:
- Brand: ELAU (Schneider Electric)
- Model: SH-140-30270-0-1-00-00-00-10-03
- Series: SH140
- Flange Size: 140 mm
- Rated Speed: 3000 RPM (indicated by ’30’)
Functional Features:
- High Torque: Optimized for applications requiring significant force.
- High Resolution Encoder: Equipped with SinCos encoder for precise feedback.
- Single Cable Technology: Simplifies installation.
- IP65 Protection: Sealed against dust and water jets.
Application Scenarios:
- Press machines.
- Heavy-duty material handling.
- Large robotics.
Performance Parameters:
- Rated Torque: 27.0 Nm (estimated based on model number).
- Control Modes: Position, Velocity, and Torque control.
- Overload Capacity: High overload capability.
Material Composition:
- High-strength aluminum housing.
- NdFeB magnets.
Structural Features:
- Compact design with high torque density.
- Standard industrial connectors.
Working Principle:
The motor operates based on the interaction of magnetic fields to generate torque. The control system adjusts the frequency and voltage of the supply to maintain precise speed and position control.
Installation Requirements:
- Ensure the mechanical system is balanced for high-torque operation.
- Use high-quality shielded cables.
- Mount securely to handle the reaction forces.
Usage Notes:
- Verify the maximum torque rating of the connected drive.
- Monitor bearing temperature during heavy load operation.
- Ensure proper grounding.
