Description
ELAU SH100-40080-0-1-00-00-00-10-00
Technical Specifications:
- Brand: ELAU (Schneider Electric)
- Model: SH100-40080-0-1-00-00-00-10-00
- Product Type: Servo Motor
- Flange Size: 100 mm
- Protection Class: IP65
- Insulation Class: F (155°C)
Functional Features:
- High Precision Control: Delivers accurate position, speed, and torque control.
- High Resolution Encoder: Equipped with a high-resolution encoder for precise feedback.
- Robust Design: Suitable for harsh industrial environments.
- Single Cable Technology: Simplifies installation and reduces wiring complexity.
Application Scenarios:
- Packaging machinery (labeling, filling, capping).
- Robotics and automated assembly lines.
- Printing and converting equipment.
Performance Parameters:
- Control Modes: Position, Velocity, and Torque control.
- Dynamic Response: High dynamic performance with fast response times.
- Torque: High torque density for its size.
Material Composition:
- Industrial-grade metal housing with epoxy coating.
- Neodymium Iron Boron (NdFeB) permanent magnets.
Structural Features:
- Compact module structure.
- IP65 rated connectors.
- Self-cooling design.
Working Principle:
The motor utilizes a permanent magnet rotor and a stator with three-phase windings. The drive supplies current to the stator, creating a rotating magnetic field that interacts with the rotor magnets to produce torque. Feedback from the encoder ensures precise closed-loop control.
Installation Requirements:
- Mount on a standard industrial flange.
- Ensure adequate ventilation for heat dissipation.
- Connect shielding cables properly to minimize EMI.
Usage Notes:
- Verify voltage rating matches the power supply.
- Ensure the connected drive is compatible with the motor’s current rating.
- Do not exceed the maximum permissible radial and axial loads on the shaft.
