ELAU SM070-60-010-P0-44-S1-B0
Technical Specifications:
- Brand: ELAU (Schneider Electric)
- Model: SM070-60-010-P0-44-S1-B0
- Product Type: Servo Motor
- Outer Diameter: 40 mm (Compact design)
- Shaft Type: Hollow Shaft
- Operating Temperature: 0°C to +100°C
Functional Features:
- Hollow Shaft: Allows for simplified mechanical integration and reduced installation complexity.
- High Frequency Response: Capable of instantaneous zeroing with frequency response up to 300kHz.
- High Precision: Equipped with an incremental encoder with magnetic pole signals.
- Modular Design: Supports plug-and-play integration with PacDrive systems.
Application Scenarios:
- Robotics (joint drives).
- Packaging machinery (high-speed pick and place).
- Automated assembly lines.
Performance Parameters:
- Power Rating: Approx. 0.54 kW.
- Supply Voltage: Typically 24V to 48V DC (verify with manual).
- Response Time: High-speed zero delay.
Material Composition:
- High-quality industrial housing.
- NdFeB permanent magnets.
Structural Features:
- Ultra-compact form factor (height < 15mm for some variants).
- Standard electrical interfaces.
Working Principle:
Converts electrical energy into mechanical rotation via magnetic field interaction. The hollow shaft design allows the motor to be mounted directly over a drive shaft, reducing backlash and inertia.
Installation Requirements:
- Ensure the hollow shaft fits securely over the mating component.
- Maintain proper clearance for heat dissipation.
- Use shielded cables for encoder and power connections.
Usage Notes:
- Confirm compatibility with the specific drive model.
- Avoid exceeding the maximum operating temperature of 100°C.
- Check axial load limits for the hollow shaft.
