Description
ELAU SM100-40-050-P0-45-S1-B0
Technical Specifications:
- Brand: ELAU (Schneider Electric)
- Model: SM100-40-050-P0-45-S1-B0
- Series: SM100
- Flange Size: 100 mm
- Protection Class: IP65 (Body) / IP64 (Shaft)
Functional Features:
- High Power Density: Delivers high torque in a compact package.
- Integrated Design: Combines motor and feedback elements.
- High Reliability: Suitable for continuous operation in harsh environments.
- Single Cable Connection: Reduces wiring complexity.
Application Scenarios:
- Packaging machinery (capping, labeling).
- Robotics.
- CNC machine tools.
Performance Parameters:
- Rated Speed: 4000 RPM.
- Rated Torque: 5.0 Nm.
- Control Precision: High precision positioning.
Material Composition:
- Industrial metal housing.
- High-grade electronic components.
Structural Features:
- Flange mounting.
- Robust housing for industrial environments.
Working Principle:
The motor utilizes a permanent magnet rotor and a stator with three-phase windings. The drive controls the current to generate a rotating magnetic field, driving the rotor. Feedback from the encoder ensures accurate closed-loop control.
Installation Requirements:
- Mount on a standard industrial flange.
- Ensure adequate ventilation.
- Connect shielding cables properly to minimize EMI.
Usage Notes:
- Verify the voltage rating matches the power supply.
- Ensure the connected drive is compatible with the motor’s current rating.
- Do not exceed the maximum permissible loads on the shaft.
