ELAU SR-058-60-005-P0-21-S1-B0-T
Technical Specifications:
- Brand: ELAU (Schneider Electric)
- Model: SR-058-60-005-P0-21-S1-B0-T
- Series: SR-058
- Flange Size: 58 mm
- Feedback: S1 (High-resolution encoder)
- Brake: B0 (No holding brake)
Functional Features:
- High Dynamics: Optimized for rapid acceleration and deceleration.
- Compact Design: Small footprint ideal for tight installation spaces.
- Precision Feedback: Equipped with a high-resolution encoder for accurate positioning.
- Thermal Protection: The “T” suffix indicates integrated thermal winding protection.
Application Scenarios:
- Precision assembly automation.
- Medical technology devices.
- High-speed pick-and-place robotics.
Performance Parameters:
- Rated Speed: 6000 RPM (indicated by ’60’).
- Control Mode: Closed-loop position, velocity, and torque control.
- Protection: Thermal monitoring integrated into the winding.
Material Composition:
- Aluminum housing for efficient heat dissipation.
- Neodymium Iron Boron (NdFeB) permanent magnets.
Structural Features:
- Flange mounting interface.
- Shielded connector for power and feedback.
- Smooth surface finish for hygiene in clean environments.
Working Principle:
The motor utilizes a permanent magnet rotor and a three-phase stator winding. The drive supplies current to create a rotating magnetic field, causing the rotor to turn. The integrated encoder provides real-time position data to the drive for closed-loop control.
Installation Requirements:
- Mount on a rigid, flat surface to ensure alignment.
- Connect the feedback cable using shielded connectors to prevent interference.
- Ensure the thermal protection circuit is correctly wired to the drive.
Usage Notes:
- Do not exceed the permissible radial and axial loads on the shaft.
- Ensure adequate cooling airflow around the motor housing.
- Verify the drive is configured for the specific encoder type (S1).
