Description
Foxboro 0399071D0303440C+0303443B
Technical Specifications
- Product Type: Composite Field Wiring Assembly.
- Components: Includes terminal block, cable, and connectors (0303440C + 0303443B).
- Signal Capacity: Supports multiple channels of analog/digital I/O.
- Environmental Rating: IP65/IP67 when properly assembled.
Functional Features
- Complete Solution: Provides all necessary wiring components in one package.
- Pre-Tested: 100% tested for continuity, insulation, and correct pinout.
- Reduced Installation Time: Eliminates field wiring errors and saves labor.
- Standardization: Ensures consistent wiring across multiple cabinets.
Application Scenarios
Ideal for large projects with repetitive I/O configurations, ensuring fast, error-free installation and commissioning.
Performance Parameters
- Insulation Resistance: >100 MΩ.
- Dielectric Strength: Withstands high-potential test.
- Temperature Rating: -40°C to +85°C.
Material Composition
Industrial-grade cable with PVC or PUR jacket. Tin-plated copper conductors. High-quality terminal blocks with nickel-plated screws.
Structural Characteristics
Pre-assembled and labeled. Includes cable glands and strain relief. Compact design for easy routing in cable trays.
Working Principle
Provides a direct, pre-wired path from the FBM’s internal electronics to the field instrument terminals, with all necessary protection and isolation built into the assembly.
