Foxboro FBM204 P0914SY
Technical Specifications
- Module Type: Combination Analog I/O Module
- Input Capacity: 8 channels of 0-20mA inputs
- Output Capacity: 8 channels of 0-20mA outputs
- Bus Interface: Foxboro Module Fieldbus
Functional Features
- Integrated AI/AO: Combines 8 AI and 8 AO channels in one module.
- Channel Isolation: Provides isolation for all input and output channels.
- Hot-Swappable Design: Supports online maintenance.
- Comprehensive Diagnostics: Reports input and output channel health.
Application Scenarios
Ideal for flow control loops, pressure regulation, and valve positioning in process industries.
Performance Parameters
- Operating Temperature: 0℃ to 60℃
- Ingress Protection: IP20
- Power Requirements: Backplane powered
Material Composition
Constructed with precision analog components and conformal-coated PCBs.
Structural Characteristics
Standard 200 Series FBM form factor. Connects via a dedicated TA with separate AI/AO sections.
Working Principle
Analog inputs are digitized via Σ-Δ converters, while outputs are generated by precision DACs. Data is exchanged over the Module Fieldbus.
Installation Requirements
Install on a 200 Series baseplate. Use shielded cables and proper grounding.
Usage Precautions
Verify AI/AO configuration in software. Ensure correct wiring polarity. Do not exceed current limits.
