Foxboro P0500JX
Technical Specifications
- Brand: FOXBORO.
- Series: I/A Series.
- Type: Communication connection cable.
- Length: Customized according to actual orders.
Functional Features
- High-Quality Construction: Manufactured with premium materials to ensure signal transmission integrity and low attenuation.
- Anti-Interference Design: Features excellent shielding performance to effectively resist electromagnetic interference in industrial sites.
- Durability: Oil-resistant, acid/alkali-resistant, and anti-aging, adapting to harsh industrial environments.
Application Scenarios
Widely used for communication connections between control stations, between control stations and operator stations, and with third-party equipment in Foxboro I/A Series DCS systems.
Performance Parameters
- Transmission Rate: Supports 10/100 Mbps Ethernet communication.
- Impedance Matching: Precise impedance design ensures minimized signal reflection.
Material Composition
The inner conductor uses high-purity oxygen-free copper, wrapped in double shielding of aluminum foil and braided mesh. The outer sheath is made of flame-retardant PVC or polyurethane material.
Structural Characteristics
- Connectors: Utilizes industrial-grade RJ-45 or dedicated circular connectors.
- Clear Markings: The cable jacket is printed with length markers and model information for easy construction and maintenance.
Working Principle
As a physical transmission medium, the P0500JX cable transmits Ethernet data via internal shielded twisted pairs using differential signaling, ensuring high-speed, lossless exchange of control commands and process data between devices.
Installation Requirements
- The bending radius must not be less than 8 times the outer diameter of the cable.
- Avoid routing parallel to high-voltage power cables; maintain a distance of at least 300mm.
- Connectors must be crimped using dedicated tools to ensure good contact.
Usage Precautions
- Strictly prohibited to pull the cable body; plug and unplug only via the connectors.
- Use a network tester to verify cable continuity and shield integrity before installation.
- Avoid exposing the cable in high-temperature or corrosive gas environments.
