Foxboro P0916BT
Foxboro P0916BT - Image 2

Foxboro P0916BT

Product Introduction

  • P0916BT is a module baseplate/mounting base used in the Foxboro I/A Series DCS to physically support and electrically connect various I/O modules, communication modules, and other system components. It provides the mechanical interface for module installation and the electrical pathways for power and communication buses, enabling modular and scalable system configurations.
Request Quote
Category: SKU: Foxboro P0916BT

Description

Foxboro P0916BT

  • Technical Specifications
    • Type: Module Baseplate / Mounting Base
    • Compatibility: Supports multiple Foxboro I/A Series modules (e.g., I/O, communication, and interface modules)
    • Mounting Options: DIN-rail mount and wall-mount configurable to suit cabinet layouts
    • Electrical Interfaces: Provides backplane connections for power (typically 24 V DC) and communication (e.g., 2 Mbps Module Fieldbus, Ethernet, depending on the modules populated)
    • Environmental: Designed for harsh industrial environments (G3-class equivalent), with operating temperature 0 °C to 60 °C and tolerance to vibration and electromagnetic interference
    • Protection: IP20 when installed in an enclosure; materials resistant to dust and humidity
    • Materials: Aluminum alloy and polycarbonate construction for strength and durability
  • Functional Features
    • Modular design supports easy insertion and removal of modules, facilitating system expansion and maintenance
    • High reliability in industrial environments, ensuring stable operation over long periods
    • Supports multiple module types, enabling flexible I/O and communication configurations
    • Simplifies wiring by integrating power and signal routing within the baseplate
  • Application Scenarios
    • DCS cabinet installations in process plants (e.g., refineries, chemical plants, power stations)
    • Control rooms and remote I/O enclosures where I/A Series modules are deployed
    • Systems requiring high availability and modular scalability
  • Performance Parameters
    • Supports standard I/A Series communication speeds and power distribution requirements
    • Maintains signal integrity and power quality across connected modules
    • Designed to meet the environmental and mechanical specifications of the I/A Series
  • Material and Structural Characteristics
    • Aluminum alloy frame provides mechanical strength and heat dissipation
    • Polycarbonate components offer electrical insulation and resistance to industrial contaminants
    • DIN-rail mounting clips allow flexible installation in standard cabinets
  • Working Principle
    • The baseplate provides physical slots for modules and includes electrical connectors that mate with module pins to distribute power and communication signals. When a module is inserted, it engages with the baseplate connectors, establishing electrical contact and securing the module mechanically.
  • Installation Requirements
    • Mount the baseplate on a DIN-rail or directly to the panel using wall-mount options
    • Ensure adequate clearance for module insertion and airflow
    • Connect system power and fieldbus cables to the baseplate as per the system wiring diagrams
    • Verify that all modules are fully seated and locked in position
  • Usage Notes
    • Avoid exceeding the mechanical load limits when fully populating the baseplate with heavy modules
    • Regularly inspect mounting hardware for tightness and signs of wear
    • Use only Foxboro-specified modules and accessories with the baseplate to maintain compatibility
