Foxboro P0940BR
Technical Specifications
- Module Type: P0940BR
- Communication Protocol: Foxboro Evo Control Network / Ethernet
- Data Rate: 100Mbps Fiber Optic Ethernet
- Bus Interface: 2 Mbps redundant HDLC fieldbus
Functional Features
- High-Speed Data Transfer: Supports 100Mbps fiber optic communication for real-time data synchronization.
- Protocol Translation: Bridges fieldbus data to standard Ethernet protocols for SCADA integration.
- Network Redundancy: Supports dual-port redundant network connections for fault tolerance.
- Diagnostic Capabilities: Real-time monitoring of network traffic and link status.
Application Scenarios
Deployed in I/A Series systems to connect controllers to Foxboro InTouch, Wonderware System Platform, or third-party SCADA systems.
Performance Parameters
- Operating Temperature: 0℃ to 60℃
- Ingress Protection: IP20
- Latency: Ultra-low latency for real-time control applications.
Material Composition
Robust industrial enclosure with high-quality fiber optic transceivers and precision network interface components.
Structural Characteristics
Standard FBM form factor with fiber optic and copper Ethernet ports on the front panel. Supports hot-swappable installation.
Working Principle
Receives process data from the controller via the fieldbus, packages it into Ethernet frames, and transmits it over the fiber optic network to supervisory systems while receiving control commands in reverse.
Installation Requirements
Install on a compatible baseplate. Connect fiber optic cables with proper bend radius and ensure clean connector surfaces.
Usage Precautions
Handle fiber optic cables with care to prevent signal degradation. Verify network configuration parameters before commissioning.
