Description
GE ASTATQC2JDA
Technical Specifications
- Product Line: GE ASTAT Series.
- Part Number: ASTATQC2JDA.
- Type: Solid State Motor Controller / Soft Starter.
- Control Logic: Analog/Digital phase control.
Functional Features
- Torque Control: Provides smooth, adjustable torque ramping for precise load acceleration.
- Energy Saving: Reduces motor voltage during light load conditions to improve power factor.
- Fault Protection: Built-in protection against phase loss, overcurrent, and overheating.
- Flexible Inputs: Accepts standard analog (0-10V, 4-20mA) and digital control signals.
Application Scenarios
Used in precision manufacturing, textile machinery, paper mills, and variable torque pump/fan applications.
Performance Parameters
- Control Resolution: High-resolution phase control for smooth motor operation.
- Response Time: Fast dynamic response to load changes.
- Thermal Capacity: Designed for continuous duty with proper cooling.
Material Composition
High-power thyristors on extruded aluminum heat sinks, with optically isolated input circuits and conformal-coated control PCBs.
Structural Characteristics
Modular design with standardized power and control connectors. Features status LEDs and test points for diagnostics.
Working Principle
Continuously monitors the AC waveform and load current, dynamically adjusting the SCR firing angle to regulate the exact amount of power delivered to the motor based on control inputs.
Installation Requirements
Securely mount to an appropriately sized heat sink. Route control cables away from high-power lines to prevent noise interference.
Usage Precautions
Ensure adequate cooling airflow. Never short the output terminals. Verify motor compatibility before commissioning.
