GE DS200HSTIG1AAA
Technical Specifications:
- Brand: General Electric (GE)
- Model: DS200HSTIG1A / DS200HSTIG1AAA
- System Series: Speedtronic Mark V
Functional Features:
- High-Speed Sampling: Capable of capturing rapid signal changes with high temporal resolution.
- Transient Recording: Stores pre-trigger and post-trigger data for post-event analysis of turbine anomalies.
Application Scenarios:
Monitoring combustion dynamics, shaft torsional vibrations, and fast-acting protective relaying in gas turbines.
Performance Parameters:
Sampling rates in the kilohertz range with deep onboard memory buffers for capturing millisecond-level events.
Material Composition:
High-speed digital PCB with advanced ADCs (Analog-to-Digital Converters) and fast memory chips.
Structural Characteristics:
Standard Mark V form factor with specialized high-bandwidth ribbon cable connectors.
Working Principle:
Continuously samples high-speed analog inputs and stores the data in a circular buffer. Upon detecting a trigger condition, it freezes the buffer and transfers the waveform data to the main processor for analysis.
Installation Requirements:
Must be installed in a slot that supports high-speed backplane communication. Use shielded cables for all high-speed signal inputs.
Precautions for Use:
Ensure the system firmware supports high-speed data acquisition. Avoid routing high-speed signal cables parallel to high-voltage power cables to prevent noise corruption.
