GE DS3800HRDA1C1C
Technical Specifications
- Channels: 16 analog inputs
- Resolution: 16-bit ADC
- Input Range: Configurable for voltage and current signals
- Isolation: Channel-to-channel galvanic isolation
Functional Features
- High Accuracy: ±0.1% full-scale accuracy for precise monitoring.
- Signal Conditioning: Built-in filtering and amplification.
- Diagnostics: Self-test capabilities for fault detection.
Application Scenarios
Gas and steam turbine control systems, power generation plants, and industrial gas compressors.
Gas and steam turbine control systems, power generation plants, and industrial gas compressors.
Performance Parameters
- Sampling Rate: 1 kHz per channel.
- Common Mode Rejection: >80 dB.
Material Composition
Precision analog components with low-drift resistors and capacitors.
Precision analog components with low-drift resistors and capacitors.
Structural Characteristics
Standard Mark IV board format with front-panel test points and LED indicators.
Standard Mark IV board format with front-panel test points and LED indicators.
Working Principle
Analog signals are conditioned, filtered, and converted to digital values by the ADC, then transmitted to the main processor via the backplane.
Analog signals are conditioned, filtered, and converted to digital values by the ADC, then transmitted to the main processor via the backplane.
Installation Requirements
Use shielded twisted-pair cables for all analog inputs. Ground shields at the panel only to prevent ground loops.
Use shielded twisted-pair cables for all analog inputs. Ground shields at the panel only to prevent ground loops.
Usage Precautions
Calibrate regularly using NIST-traceable standards. Avoid routing signal cables near high-voltage conductors.
Calibrate regularly using NIST-traceable standards. Avoid routing signal cables near high-voltage conductors.
