Description
GE GB320L4XXXRXXXX
Technical Specifications:
- Brand: General Electric (GE)
- Model: GB320L4XXXRXXXX
- Product Type: Circuit Breaker / Switchgear
Functional Features:
- Arc Flash Mitigation: Advanced arc chute design to safely extinguish electrical arcs.
- Adjustable Trip Settings: Customizable overcurrent and ground fault protection curves.
Application Scenarios:
Industrial power distribution panels, motor control centers (MCC), and backup generator systems.
Performance Parameters:
High interrupting capacity with precise trip coordination.
Material Composition:
Thermoset plastic housing with silver-alloy contacts and copper busbars.
Structural Characteristics:
Plug-in or bolt-on mounting configuration with mechanical trip indicators.
Working Principle:
Monitors current flow continuously; when a fault condition exceeds the preset threshold, the internal mechanism physically separates contacts to interrupt the circuit.
Installation Requirements:
Must be installed by qualified electricians following NEC/IEC standards. Torque all bus connections to manufacturer specifications.
Precautions for Use:
Perform regular maintenance testing to verify trip functionality. Never operate a breaker that has experienced a major fault event without thorough inspection.
