Description
GE IC086SLM082 Technical Specifications:
- Port Configuration: 8 x 10/100Base-T(X) electrical ports and 2 x 100/1000Base-X SFP fiber slots.
- Network Redundancy: Supports Redundant-Ring technology (single ring up to 250 nodes, self-healing time <10ms), RSTP/STP (IEEE 802.1W/D).
- Operating Temperature: Wide temperature range of -40°C to +70°C.
- Management: Configurable via Windows-based PACSystems Ethernet Switch Configuration Tool.
Functional Features:
- Rapid Fault Recovery: The Redundant-Ring technology ensures uninterrupted communication by rapidly recovering from network faults in under 10 milliseconds.
- Fiber Optic Uplinks: Dual SFP slots allow for long-distance, noise-immune fiber optic connections between control cabinets.
- Centralized Management: Enables comprehensive network monitoring, configuration, and diagnostics from a central PC.
- Industrial Hardening: Designed to withstand extreme temperatures, electrical noise, and mechanical vibration.
Application Scenarios:
- Network backbone for GE PACSystems PLC and HMI networks.
- Substation automation and power distribution monitoring.
- Manufacturing execution systems (MES) and SCADA networks.
Performance Parameters:
- Switching Architecture: Store-and-forward switching for error-free data transmission.
- Latency: Ultra-low latency for real-time industrial control applications.
- Power Supply: Redundant DC power input for high availability.
Material Composition & Structural Characteristics:
- Enclosure: Heavy-duty metal chassis for superior EMI shielding and heat dissipation.
- Mounting: DIN-rail mountable design for easy integration into industrial control panels.
- Connectors: Industrial-grade RJ45 and SFP connectors with secure latching mechanisms.
Working Principle: The switch receives Ethernet frames on its electrical or fiber ports, inspects the destination MAC address, and forwards the frame only to the appropriate
