Description
GE IC200ALG328J Technical Specifications
-
Output Channels: 12 single-ended, one group
-
Resolution: 13-bit
-
Output Range: 4–20 mA (default), 0–20 mA (jumper-configurable)
-
Output Current per Channel: Approximately 20.38 mA for driving loads
-
Update Rate: 15 milliseconds
-
External Power Supply: 18–30 VDC
-
Backplane Current Consumption: 50 mA from +5V bus
-
Isolation: 250 VAC continuous; 1500 VAC for 1 minute
-
LED Indicators: FLD PWR, OK
-
Operating Temperature: Industrial standard range
Functional Features The module delivers high-precision analog current outputs across 12 independent channels. Each channel supports the same current range configuration via jumpers as the 8-channel variants. The increased channel density makes it ideal for applications requiring multiple control loops in space-constrained installations. External power is required for all output circuits.
Applications
-
Multi-loop process control systems
-
Building automation with extensive actuator networks
-
Water treatment facility chemical feed control
-
Manufacturing lines with numerous variable speed drives
