Description
GE IC200MDL241 Technical Specifications:
- Inputs: 16 points, grouped in two banks of 8.
- Input Voltage: 240VAC nominal (operating range typically 120-264VAC).
- Input Current: Typically 10mA per point at 240VAC.
- Isolation: 2500V AC isolation between input groups and backplane.
Functional Features:
- Direct AC Interface: Connects directly to AC control circuits and limit switches.
- High Isolation: Robust isolation for safe operation in high-voltage environments.
- Zero-Crossing Detection: Reduces EMI generation and provides clean switching.
Application Scenarios:
- Motor control center (MCC) status monitoring.
- High-voltage limit switch and interlock inputs.
- Legacy equipment retrofit where AC control signals are prevalent.
Material Composition & Structural Characteristics:
- Safety Markings: Clearly marked with high-voltage warnings and AC ratings.
- Terminal Protection: Shrouded terminals to prevent accidental contact with live AC voltages.
Working Principle: The module uses opto-isolators with integrated rectifiers and current-limiting resistors to safely convert 240VAC signals to logic-level DC for the backplane.
Installation Requirements:
- Safety: Always de-energize the AC circuit before wiring or servicing.
