GE IC693CMM321 Technical Specifications:
- Interface: 10/100 Base-T Ethernet (RJ-45)
- System Compatibility: GE Fanuc Series 90-30 PLC
- Protocol Support: TCP/IP, UDP/IP, SNPX over Ethernet
- Connections: Supports multiple simultaneous TCP connections
Functional Features:
- Network Integration: Seamless connection to standard Ethernet infrastructure.
- High-Speed Communication: Faster data transfer than serial alternatives.
- Multi-Protocol Support: Native support for GE SNPX and standard TCP/IP.
- Diagnostics: Built-in network diagnostics and status LEDs.
Application Scenarios:
- SCADA and DCS integration.
- HMI and operator interface connectivity.
- Peer-to-peer PLC data exchange.
- Remote monitoring and data logging.
Performance Parameters:
- Network Speed: 10/100 Mbps auto-negotiation.
- IP Configuration: Static IP or DHCP (depending on firmware).
- Socket Support: Multiple TCP/UDP sockets.
Material Composition & Structural Characteristics:
- Enclosure: Standard Series 90-30 module.
- Connector: Front-panel RJ-45 Ethernet port.
- Indicators: Link, Activity, and Status LEDs.
Working Principle: The module contains an Ethernet controller and TCP/IP stack. It encapsulates PLC data into Ethernet frames for network transmission and processes incoming Ethernet packets to extract PLC commands and data.
Installation Requirements:
- Slot: Any available I/O slot.
- Cabling: Standard CAT5e/CAT6 Ethernet cable.
- Configuration: Assign IP address, subnet mask, and gateway via programming software.
Usage Precautions:
- Network Design: Ensure proper IP addressing and subnetting.
- Firewalls: Configure network firewalls to allow PLC traffic.
- Firmware: Verify Ethernet module firmware is compatible with CPU firmware.
- Security: Implement network security best practices for industrial Ethernet.
