GE IC693CPU372-AB

GE IC693CPU372-AB

Product Brief The GE IC693CPU372-AB is a single-slot modular CPU module from GE Fanuc’s Series 90-30 family of programmable logic controllers. This module features a built-in Ethernet interface for TCP/IP communication, making it ideal for networked industrial automation applications. The AB revision represents a specific factory-certified engineering revision with upgraded component tolerances. The CPU372 is designed to work with Series 90-30, PACSystems, and VersaMax PLCs, providing a versatile control platform for mid-range industrial applications.

Request Quote
Category:

Description

GE IC693CPU372-AB

Technical Specifications

  • Part Number: IC693CPU372-AB
  • Manufacturer: GE Fanuc
  • Series: Series 90-30
  • Product Type: Single-Slot Modular CPU with Ethernet Interface
  • Processor Type: AMD SC520
  • Processor Speed: 133 MHz
  • User Program Memory: 240 Kbytes
  • Register Memory: 240 kilobytes
  • Discrete Input Points (%I): 2,048 (fixed)
  • Discrete Output Points (%Q): 2,048 (fixed)
  • Discrete Global Memory (%G): 1,280 bits (fixed)
  • Internal Coils (%M): 4,096 bits (fixed)
  • Temporary Coils (%T): 256 bits (fixed)
  • System Status References (%S): 128 bits (fixed)
  • Register Memory (%R): Configurable 128 to 32,640 words
  • Analog Inputs (%AI): Configurable 128 to 32,640 words
  • Analog Outputs (%AQ): Configurable 128 to 32,640 words
  • System Registers (%SR): 28 words (fixed)
  • Timers/Counters: Greater than 2,000 (depends on available memory)
  • Ethernet Ports: 2 x 10BaseT / 100BaseTX RJ-45, auto-sensing
  • Communication Protocols: TCP/IP, Modbus TCP/IP, SRTP
  • Supported Networks: 100BaseTX IEEE 802.3 / 10BaseT
  • Execution Time: 0.15 msec per Boolean instruction
  • Floating Point Math: Yes, hardware-based with built-in math co-processor
  • Battery-Backed Clock: Yes
  • Internal Power Used: 1.4 Amps at 5 VDC (high-capacity power supply required)
  • Total Baseplates per System: 8 (CPU baseplate + 7 expansion/remote)
  • Memory Storage: RAM and Flash
  • System Version: 32-bit

Key Features

  • 133 MHz AMD SC520 processor for fast execution
  • Built-in dual 10/100 Mbps Ethernet ports with auto-sensing
  • TCP/IP and Modbus TCP/IP protocol support
  • SRTP server capability for client requests
  • Hardware floating-point math co-processor
  • Large configurable memory space
  • Battery-backed real-time clock
  • Support for up to 7 expansion and 7 remote I/O baseplates
  • Compatible with Series 90, PACSystems, and VersaMax PLCs
  • Web diagnostic capabilities
  • Front panel with ON/OFF switch, 8 status LEDs, Ethernet restart button

Application Scenarios Industrial automation control, manufacturing process control, material handling systems, packaging machinery, water/wastewater treatment, building automation, food and beverage processing, automotive assembly lines
