Description
GE IC695CPE302
Technical Specifications
| Parameter | Specification |
|---|---|
| Processor | 300 MHz Intel XScale |
| User Memory | 10 MB (configurable for program, data, and retentive storage) |
| I/O Capacity | Up to 32,768 digital I/O or 4,096 analog I/O |
| Programming Languages | Ladder Logic, Structured Text, Function Block Diagram (IEC 61131-3) |
| Communication Ports | 2 × Ethernet (10/100BaseT), 1 × RS-232, 1 × RS-485, 1 × USB |
| Supported Protocols | Modbus TCP, EGD, Profibus DP (via module), Profinet (via module) |
| Operating Temperature | 0°C to 60°C |
| Humidity | 5% to 95% (non-condensing) |
| Power Supply | Requires compatible RX3i power supply (e.g., IC694PWR330) |
| Dimensions | Standard RX3i module size |
Functional Characteristics
- High Performance: 300 MHz processor enables fast logic execution and complex algorithm processing.
- Large Memory: 10 MB of user memory supports extensive programs, data tables, and historical logging.
- Versatile Communication: Built-in Ethernet ports support high-speed networking, while serial ports enable legacy device connectivity.
- IEC 61131-3 Compliance: Supports multiple programming languages for flexibility in application development.
Application Scenarios
- Complex Manufacturing: Coordinating multiple production lines, robotic cells, and quality stations.
- Process Control: Managing continuous processes like chemical dosing, temperature control, and flow regulation.
- SCADA Integration: Serving as a gateway between field devices and higher-level control systems.
- Energy Management: Monitoring and optimizing power consumption in industrial facilities.
Installation & Usage Notes
- Requires a compatible RX3i backplane (e.g., IC695CHS007) and power supply.
- Use GE Machine Edition software for programming, configuration, and diagnostics.
- Ensure proper cooling for the CPU in high-temperature environments.
- The CPU supports firmware updates for new features and bug fixes.
