Description
GE IC697CHS770
Technical Specifications:
- Slot Count: 17 double-wide slots (plus power supply slot)
- Mounting: Rear (panel) mount
- Rack Type: Redundant-capable (supports dual CPUs and dual power supplies)
- Compatibility: All IC697 modules, including CPU, power, I/O, and communication modules
- Backplane: VME64-compatible for high-speed module communication
- Dimensions: Approximately 11.15 x 19.00 x 7.5 inches
- Material: Steel enclosure for durability and EMI shielding
- Operating Environment: 0°C to 60°C; 5% to 95% humidity non-condensing
Functional Features:
- Supports high-availability configurations with redundant CPUs and power supplies.
- Modular design allows flexible system configuration and expansion.
- High-speed backplane ensures rapid data exchange between modules.
Application Scenarios:
- Critical process control systems requiring redundancy for high availability.
- Large-scale automation installations with numerous I/O and communication modules.
Performance Parameters:
- Provides stable power distribution and signal integrity across all slots.
- Designed to minimize noise and crosstalk in complex systems.
Material and Structural Characteristics:
- Heavy-duty steel construction for protection in industrial environments.
- Integrated backplane with keyed connectors to prevent incorrect module insertion.
Working Principle: The rack houses and connects all modules via the backplane, distributing power and providing data paths. In redundant configurations, it enables seamless switchover between primary and standby CPUs and power supplies. Installation Requirements:
- Mount securely in a cabinet or panel with adequate ventilation.
- Ensure proper grounding of the rack chassis.
- Install power supply modules in designated slots before adding other modules.
Usage Notes:
- Follow recommended airflow and clearance guidelines to avoid overheating.
- Use appropriate cable management to maintain accessibility and reduce strain on connectors.
