  • Product Introduction: This is a single-port 10/100 Mbps Ethernet communication module for the GE Fanuc 90-70 PLC. It provides one RJ-45 Ethernet port with full TCP/IP stack support, enabling the PLC to connect to SCADA systems, HMIs, and other Ethernet devices. Unlike the IC697CPM790, this is a single-port module with an embedded web server for remote diagnostics and configuration. It is a cost-effective solution for applications requiring only one Ethernet connection.
Request Quote
Category: SKU: GE IC697CPX782

Description

GE IC697CPX782

  • Technical Specifications:
    • Ports: 1 x RJ-45 10/100Base-TX Ethernet
    • Speed: 10/100 Mbps auto-negotiation
    • Protocols: TCP/IP, UDP/IP, Modbus TCP, HTTP, FTP, SNMP v1/v2c, DHCP, DNS, EtherNet/IP (explicit messaging)
    • Max Connections: 64 simultaneous TCP/IP connections
    • Buffer Size: 64KB
    • Backplane Interface: IC697 Genius Bus
    • Power Supply: 5VDC from backplane (400mA typical)
    • Operating Temperature: 0°C to 60°C
    • Dimensions: Standard IC697 module form factor
  • Functional Features:
    • Single Ethernet port with full TCP/IP stack
    • Embedded web server — access PLC status via any web browser
    • SNMP support for network monitoring
    • FTP/TFTP client for file transfer and firmware updates
    • Email alarm notification capability
    • LED indicators: Link, Activity, Fault
    • Compatible with 90-70 PLC programming software
  • Application Scenarios:
    • SCADA communication via Ethernet
    • Remote monitoring using web browser
    • Modbus TCP client/server communication
    • Email alarm notifications
    • Simple peer-to-peer Ethernet messaging
    • Firmware upgrades via TFTP/FTP
  • Performance Parameters:
    • Throughput: Up to 80 Mbps (TCP)
    • Latency: <2ms local network
    • Isolation: Magnetic isolation (transformer) on Ethernet port
    • ESD Protection: ±8kV contact
    • EMC Compliance: EN 61131-2, FCC Part 15
  • Material Composition:
    • Housing: UL94 V-0 ABS/polycarbonate
    • PCB: 4-layer FR-4, conformal coated
    • Connectors: RJ-45 magnetic jack, gold-plated backplane edge connector
    • Isolation: Pulse transformer for Ethernet port
    • LEDs: Green, Yellow, Red
  • Structural Features:
    • Standard IC697 module size
    • 1 RJ-45 port on front panel
    • 3 LED indicators (Link, Activity, Fault)
    • DIN-rail or chassis mount
  • Working Principle:
    • Similar to IC697CPM790 but with a single Ethernet controller. The CPU writes data to the module’s dual-port RAM via the Genius Bus. The Ethernet controller encapsulates data into TCP/IP packets and transmits via the RJ-45 port. Incoming packets are decapsulated and payload written to dual-port RAM for CPU access. The embedded web server runs on a small RTOS within the module’s processor.
  • Installation Requirements:
    • Mount in IC697 chassis
    • Connect Cat5e/Cat6 cable to RJ-45 port
    • Configure IP settings in PLC software
    • Enable the Ethernet port in CPU configuration
  • Usage Precautions:
    • Use shielded cable in noisy environments
    • Do not exceed 100m cable length
    • Set static IP or use DHCP consistently
    • Do not expose the web server to untrusted networks without authentication
    • Keep firmware updated
